Aerpro AM9670PK 7" HEADUNIT TO SUIT FORD TERRITORY SZ MK2 GLOSS

The Aerpro AM9670PK package offers a comprehensive head unit upgrade solution that includes an Aerpro AM7X Double DIN 7" Mechless AV Receiver, a Vehicle Specific Installation Kit and a 720P AHD universal reverse camera. Designed specifically for Ford Territory SZ MK2 (2015-2016) vehicles, this package comes with all the necessary parts to complete the installation and retain important features such as steering wheel controls.

Aerpro AM7X 7" Multimedia Receiver with Wireless CarPlay and Android Auto

The Aerpro AM7X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 7" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 45W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has dual reverse camera inputs (720P AHD compatible).

Vehicle Specific Installation Kit

The Aerpro Vehicle Specific Installation Kit is designed to provide a complete solution for upgrading the head unit in Ford Territory SZ MK2 (2015-2016) vehicles. The kit contains all necessary components for a successful double din installation, including a piano black facia kit, HVAC controller and steering wheel control interface, a vehicle specific wiring loom, a video in/out loom, a reverse camera retention lead, a factory parking tone retention module, a subwoofer retention lead, a universal patch lead and an antenna adaptor

720P AHD Surface Mount Camera

The Aerpro 720P AHD Surface Mount Camera produces high definition picture quality. The camera can be used as a front, rear or reverse camera. It features a 150 degree field of view, optional parking guidelines and is IP67 rated. The camera is designed to mount on a flat surface and has an adjustable bracket to enable angle adjustment.

Important Information:

Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
This head unit is sold as a kit which includes:
Aerpro AM7X 7" Multimedia Receiver with Wireless Carplay and Android Auto
Vehicle Specific Installation Kit
720P AHD Surface Mount Camera
Specification
Aerpro AM7X Specifications:

LCD Display:
Size: 7"
Resolution: 1024x600
Touch Screen: Capacitive (G+G)
System Specifications:
OS System / CPU: Linux 3.4.5 / SPHE8368U
RAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output
Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
MAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports
USB (Rear) Playback Formats: CPAA & Media
USB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5A
USB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:
Rear A/V Input (RCA Type - 3pcs): Yes
Reverse Camera Input: Yes (720P AHD Compatible)
Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:
Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
Bluetooth Version: V4.2+EDR
Microphone: Built-in & External Microphone
ID3 Tag/Information (Artist, Album, Song): Yes
HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:
AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
RDS: Yes
FM Antenna Connector Impedance: 50 Ohm
FM Tuner Connector: Motorola
RCA Preamp Outputs:
RCA Preamp Output: 2-Pair (Front / Rear)
Subwoofer RCA Output: Yes
Subwoofer Level Control: Yes
Preamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:
8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
Loudness: Yes
LPF - Frequencies (Sub): Yes
8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:
Steering Wheel Control: Yes, with Aerpro SWC Adaptor
OSD Language: English
LED Colour (Buttons / Keys): White
Accessories:
Power Harness: Yes with ISO
AV-In Cable (RCA with Audio L/R, Video In): Yes
Reverse Camera Input: Yes
4.2CH Audio Out Cable: Yes
External Microphone: Included
Vehicle Specific Installation Kit Specifications:

Inclusions:
Facia Kit (Piano Black)
HVAC controller and steering wheel control interface
Reverse camera and Subwoofer retention lead
Steering Wheel Control Interface
Universal Patch Lead
AHD Camera Specifications:

Inclusions:
720P AHD Surface Mount Camera (wired)
6m of Video Cable (RCA) with in-line Reverse Trigger
Mount Type: Surface Mount
Camera Type: Front, Rear Or Reverse
Image Sensor: Sony 225, 1/3 CMOS AHD
Lens Angle 150 Degree
Important Information:

Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
This head unit is sold as a kit which includes:
Aerpro AM7X 7" Multimedia Receiver with Wireless CarPlay and Android Auto
Vehicle Specific Installation Kit
720P AHD Surface Mount Camera
Features
Includes all the parts required to complete the installation
Retains steering wheel control functionality and factory reverse camera when connected to compatible aftermarket head units
Retains factory parking sensor tones with the included module
Includes integrated buttons for adjusting climate control and various vehicle settings
Climate control and vehicle information display on the aftermarket AV head unit
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired) and Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera input with 1 Aerpro 720P AHD Camera included
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ with 8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
