Aerpro AMVW2 10" Wireless Apple CarPlay Android Auto Head Unit To Suit VW various 04-16

The Aerpro AMVW2 10" Multimedia Receiver with Wireless Apple CarPlay and Android Auto suits Volkswagen Amarok (2011-2016)*, Beetle (2012- 2014), Caddy (2005-2015), Eos (2007-2014), Golf (2004-2013)*, Jetta (2006-2015)*, Passat (2006-2015)*, Polo (2010-2015)*, Scirocco (2009-2014)*, Tiguan (2008-2014)* and Transporter (2010-2015) vehicles. Featuring a large 10" capacitive touchscreen display, this Multimedia Receiver has Apple CarPlay and Android Auto which can be used wireless or wired, built-in Bluetooth for hands-free phone calls & wireless audio streaming, rear USB input as well as an AM/FM radio tuner. Sound quality is superb with 40Wx4 max output, 8 band graphic EQ and time alignment capabilities, amplifiers can be added to the system via the 4V/5CH RCA preouts. Supplied as a complete Head Unit Upgrade Kit, the Aerpro AMVW2 includes all the parts required to complete the installation and retains important vehicle features including steering wheel controls and the factory amplified system (model dependant**).

Hema Maps Ready

Experience seamless on-road and off-road navigation through the head unit display by adding the optional AerproAMHXD3On-Road / Off-Road Navigation Module (sold separately).

Important Information:

• Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
• (*) Due to the size of the head unit, please be aware of the following:
  • Amarok (2011-2016): Kit may partially cover top buttons.
  • Golf (2004-2009): Kit covers vent dial, may still be accessible but not tested.
  • Jetta (2006-2011): Kit covers vent dial, may still be accessible but not tested.
  • Passat (2006-2015): Kit covers part of hazard or clock on some models.
  • Polo (2010-2015): Kit covers part of buttons.
  • Scirocco (2009-2014): Kit covers vent adjusters.
  • Tiguan (2008-2014): Kit partially covers hazard button.
• (**) Factory amplifier retention:
  • Compatible with factory Panasonic amplified systems.
  • Not compatible with factory Blaupunkt amplified systems, for these vehicles please use the Aerpro AMVW3 Head Unit Upgrade Kit.
  • May need a trigger wired in for the amplifier.
• This head unit is sold as a kit which includes:
  • AM10XMultimedia Receiver
  • Matte Black Facia Kit
  • Steering Wheel Control Interface Harness
  • SWC Patch Lead
  • Amplifier Retention Harness
  • Antenna Adaptor

Features:

• To suit Volkswagen Amarok (2011-2016)*, Beetle (2012- 2014), Caddy (2005-2015), Eos (2007-2014), Golf (2004-2013)*, Jetta (2006-2015)*, Passat (2006-2015)*, Polo (2010-2015)*, Scirocco (2009-2014)*, Tiguan (2008-2014)* and Transporter (2010-2015) vehicles
• Includes all the parts required to complete the installation
• Apple CarPlay & Android Auto (wireless / wired)
• Hema Maps Ready, experience seamless on-road and off-road navigation through the head unit display (optional AMHXD3 required, sold separately)
• Large 10" capacitive touchscreen display
• Steering wheel control and factory amplified system (model dependant**) retention
• Bluetooth with external microphone included (A2DP, AVRCP, HFP, PBAP)
• AM / FM Tuner with RDS & presets (18FM/12AM)
• Rear USB input (1.5A max charging)
• Reverse camera input (AHD 720P compatible) & rear A/V input
• 40Wx4 Max with 8 band graphic EQ and time alignment capabilities
• 4V/5CH RCA Preout and subwoofer level control

AMVW2 HEAD UNIT UPGRADE KIT SPECIFICATIONS:

• Kit Inclusions:
  • AM10X Multimedia Receiver
  • Matte Black Facia Kit
  • Steering Wheel Control Interface Harness
  • SWC Patch Lead
  • Amplifier Retention Harness
  • Antenna Adaptor
• Vehicle Feature Retention:
  • Steering Wheel Controls: Yes (including phone button)
  • Factory Reverse Camera: No
  • AUX Input: N/A
  • USB Input: N/A
  • Parking Tones: No
  • Factory Amplifier: Yes (model dependant**)
  • Vehicle Menu: N/A
  • Other: N/A

AM10X MULTIMEDIA RECEIVER SPECIFICATIONS:

• LCD Display:
  • Size: 10"
  • Resolution: 1024x600
  • Touch Screen: Capacitive (G+G)
• System Specifications:
  • OS System / CPU: Linux 3.4.5 / SPHE8368U
  • RAM / Flash Memory: 128MB / 256MB
• DIN Size: 2 DIN Short Body
• Power Output
  • Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
  • MAX Power (4 Ohm): 4CH x 40W
• Media Playback: MP3 / AAC / FLAC / Xvid / MPEG 1, 2, 4
• Device Ports
  • USB (Rear) Playback Formats: CPAA & Media
  • USB (Rear) Power - Voltage/Amps: 5V/1.5A
  • USB MAX Capability: FAT32_32GB
• Aux Inputs / Outputs:
  • Rear A/V Input (RCA Type - 3pcs): Yes
  • Composite Video Outputs: Yes
  • Reverse Camera Input: Yes (720P AHD Compatible)
• Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
• Bluetooth:
  • Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
  • Bluetooth Version: V4.2+EDR
  • Microphone: Built-in & External Microphone
  • ID3 Tag/Information (Artist, Album, Song): Yes
  • HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
• Tuner:
  • AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
  • FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
  • AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
  • RDS: Yes
  • FM Antenna Connector Impedance: 50 Ohm
  • FM Tuner Connector: Motorola
• RCA Preamp Outputs:
  • RCA Preamp Output: 2-Pair (Front / Rear)
  • Subwoofer RCA Output: Yes
  • Subwoofer Level Control: Yes
  • Preamp Voltage (1.2,2,4,5,6): 4V p-p
• Tone Control:
  • 8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
  • Loudness: Yes
  • LPF - Frequencies (Sub): Yes
  • 8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
• Other Features:
  • Steering Wheel Control: Yes, with Aerpro SWC Adaptor
  • OSD Language: English
  • LED Colour (Buttons / Keys): White
• Accessories:
  • Power Harness: Yes with ISO/3.5mm jack
  • AV-In Cable (RCA with Audio L/R, Video In): Yes
  • Reverse Camera Input (with 12V power supply to the camera): Yes
  • 4.1CH Audio Out Cable: Yes
  • External Microphone: Included

Vehicles known to work with this product:

• Volkswagen Amarok 2011-2016
• Volkswagen Beetle 2012-
• Volkswagen Caddy 2005-2015
• Volkswagen EOS 2007-2014
• Volkswagen Golf 2004-2009 MK5
• Volkswagen Golf 2009-2013 MK6
• Volkswagen Jetta 2006-2015
• Volkswagen Passat 2006-2015
• Volkswagen Polo 2010-2014
• Volkswagen Scirocco 2009-2014
• Volkswagen Tiguan 2008-2014
• Volkswagen Transporter T5 2010-2015
