Audison APBX10S4 Prima Line Active Subwoofer

Description

The APBX 10 S4S sealed enclosure is the ideal choice to be driven by the new AP F8.9 bit using two channels bridged. Designed to house the single 4 ohm voice coil APS 10 S4S subwoofer, it offers an ultra - performing Plug & Play solution boasting all the features that make the Prima boxes unique such as the SSP (Sub Smart Plug) terminal block for a quick connection leaving no room for errors.

Specification
PRIMA LINE SUBWOOFER BOX

Component Passive Sealed Sub Box
Subwoofer size mm (in.) 250 (10)
Power Handling
800W peak
400W continuous
Impedance 4 Ohm
Sub box size mm (in.) 470 (18.5) x 142 (5.59) x 334 (13.15)
Weight of one component kg (lb.) 8,63 (19.03)
Magnet High density flux ferrite
Cone Water - repellent pressed paper
Subwoofer Voice coil mm (in.) 60 (2.36)

Features

Ultra - low profile (5.6 in. / 142 mm) box with sealed design perfectly tuned to fully exploit the APS 10 S4S driver.
2S2 (2 Sides/2 Sounds) design provides the ability to choose between Down - Firing mounting to increase the low - frequency extension and Up - Firing install to obtain more punch and definition.
Levelling feet with velcro inserts included for a secure grip with the carpet while maintaining easy removal.
SSP (Sub Smart Plug) features both traditional push contacts and a Plug - & - Play terminal block to easily configure the impedance as required and provides a quick release.
Rounded corners allow easy positioning in the trunk and act as reinforcement to reduce enclosure resonance.
Special designed cone - dust cap - basket geometry which guarantees a long linear excursion capability (11 mm, one - way).
Massive driver motor assembly, optimized with FEM (Finite Element Modelling) for perfect control under high excursion conditions.
Water - repellent pressed paper 10 in. cone, featuring a profile developed with FEM simulation and optimized with the Klippel Scan Vibrometer.
Sturdy metal grid included for a total protection of the subwoofer driver

(APBX10S4)
