Audison SR 5.600 600 Watt 5 Channel Amplifier

Power Output (RMS) @14.4 VDC, 1% THD

• 5 Channels - 75 Watts x 4 + 330 Watts x 1 @ (4Ω)
• 5 Channels - 115 Watts x 4 + 550 Watts x 1 @ (2Ω)
• 3 Channels - 230 Watts x 2 + 310 Watts x 1 @ (4Ω)
• 3 Channels - 230 Watts x 2 @ (4Ω) + 550 Watts x 1 @ (2Ω)

Features

• ADC (Audison D-Class) Technology 2Ω stable output stage ensuring high audio performance in a compact size.
• Extruded aluminum compact design with fan less convection cooling system.
• Built-in USS (Universal Speakers Simulator).
• Balanced high-noise rejection input speaker-In (for OEM head units) and RCA-In (for Aftermarket head units) inputs.
• ART (Automatic Remote Turn-On/Off) automatically turns on/off the amplifier when the OEM head-unit turns on/off (can be enabled/ disabled, with Speaker-In inputs).
• Pre-outs, also available when using Speaker-In level inputs.
• 5 ch/3 ch operation mode (selectable), to create a five-channel system (with sub), or a powerful sub + front three-channel system.
• Bass Boost (50 Hz) adjustable to 12 dB, to increase the subwoofer punch.
• Lo-Pass and Hi-Pass 12 dB adjustable (50 Hz to 3200 Hz) filters, providing the ability to build a front + rear system, a multichannel wooer + tweeter system or a powerful sub + front system.
• 24 dB continuous adjustable (50 to 500 Hz) Lo-Pass subwoofer filter.
• SUBSONIC filter (24 dB - 25 Hz), removes very low subsonic frequencies from music signal to avoid damages to the subwoofer.
• Optional VCR-S1 Remote Volume Control providing the ability to adjust subwoofer volume level from the dashboard.
