ARJ45JP1: RJ45 PASS-THROUGH ADAPTOR TO SUIT JEEP (20.5MM X 32MM)

Aerpro ARJ45JP1 RJ45 Pass-Through Adaptor has been designed specifically to suit various Jeep vehicles. It replaces the spare factory switch blanking plates in the vehicle dashboard that measure 20.5mm wide x 32mm high (face measurement) / 24mm wide x 36.5mm high (base measurement), providing a professional and seamless integration solution for your vehicle when installing a hideaway UHF radio with remote microphone. The connection type is RJ45 pass-through, the cable supplied with the hideaway UHF radio plugs into the rear of the adaptor, while the plug on the end of the remote microphone will plug into the face of the adaptor. The UHF RADIO text illuminates blue making it easy to find day and night and the clip-in design combined with the simple 2 wire connection for illumination, makes it quick and easy to install.

Features:

• Suitable for Jeep vehicles with 20.5mm wide x 32mm high (face) / 24mm wide x 36.5mm high (base) switch blanking plates
• Replaces factory switch blanking plates in the dashboard
• Vehicle specific OEM style design for discreet seamless integration
• RJ45 Pass-through connector, suitable for UHF radios that have an RJ45 microphone connection (most major brands)
• Cable supplied with the UHF radio plugs into the rear of the connector
• Cable from the UHF radio microphone plugs into the front of the connector
• UHF RADIO text illuminates blue making it easy to find day and night
• Simple clip-in design makes it easy to install with no modifications required
• Easy two wire installation: connect the red wire to the vehicle's 12v dash light circuit and the black wire to the negative circuit

Specs:

• VEHICLE APPLICATION: VARIOUS JEEP VEHICLES
• PANEL DIMENSIONS:
  • BODY: 24MM (W) X 36.5MM (H)
  • FACE: 20.5MM (W) X 32MM (H)
• CONNECTION TYPE: RJ45 PASS-THROUGH
• MOUNTING TYPE: CLIP-IN
• WIRING INSTALLATION:
  • 12V+ DASH LIGHT CIRCUIT: RED
  • EARTH: BLACK
• NOTES: N/A

Vehicles known to work with this product:

• Jeep Cherokee 2001-2007 KJ
• Jeep Wrangler 1997-2002 TJ
• Jeep Wrangler 2003-2007 TJ
